Tilted Ergonomic Design
Complete operation performed from one position & Unobstructed access to the lower bead eases lubrication

Bead Press Arm
Helps mount difficult tires & Holds sidewalls into drop-center position

Blast Inflation
Directs bursts of compressed air to easily seat the bead

Adjustable Column
12" to 28" range

Motor and Drive - TC
15- and 7-rpm clockwise speeds, 15 rpm counterclockwise speed & 850-ft-lbs. of torque

PowerOut™ Bead Loosener - Optional
Ergonomic control handle makes large assembly service easy & Familiar side shovel design with standard protector sleeve

Mount/Demount Head
Polymer mount/demount head resists marring rims & Vertical locking head for wheel face protection

Split Bead Roller System
Perform all bead breaking upright, Match mounting made easy & Easy bottom bead demounting

Center-Clamp Design
Simple clamping technique for all designs, Cam action multiplies clamping force & Three height positions.
